Raspberry Pi 400 4GB Official Start-up Kit

The Raspberry Pi Pico W, also with pre-soldered headers, allows users to easily add wireless connectivity to builds and IoT projects. The board has been pre-fitted with a pre-soldered 40-way header connector, for greater ease of use in hobbyist and industrial applications.

At the heart of this microcontroller is RP2040, a Raspberry Pi-designed chip. The Raspberry Pi Pico, it's; small, fast, highly affordable, and incredibly versatile. Brought to you by the same team that delivered the Raspberry Pi computer. The powerful, Pi-designed, RP2040 Dual ARM Cortex-M0+ @ 133MHz chip features 256KB internal RAM. This is paired with 2MB of onboard QSPI Flash memory for code and data storage. The board is fully loaded with the hardware and flexible I/O options that make it perfect for beginners and experts alike.

Unlike the Raspberry Pi computers, like the Raspberry Pi 4, the pico has no operating system. Instead, the board is programmed to do only the tasks that are required of it in the project it will be used for. It can be programmed with the C/C++ SDK or with MicroPython. Code on your Desktop Computer/Pi and then transfer via USB to the Pico.

The Raspberry Pi Pico W, also with pre-soldered headers, allows users to easily add wireless connectivity to projects. This makes it perfect for wirelessly controlled builds and IoT projects.

On-board single-band 2.4GHz wireless interfaces (802.11n) via Infineon CYW43439 wireless chip. With WPA3 & soft access point supporting up to 4 clients.

The Raspberry Pi Pico board is a new cutting-edge microcontroller that features the Pi-designed ARM-based dual-core RP2040 chip.

The RP2040 is a Dual ARM Cortex-M0+ @ 133MHz chip.

256kB on-chip SRAM.

Support for up to 16MB of off-chip Flash memory.

Pre-soldered header pins so no user soldering is required.

Micro USB port, power and data (USB 1.1 with device and host support).

Drag & drop programming via USB.

Low-power sleep and dormant modes.

Accurate clock and timer on-chip.

Temperature sensor.

Accelerated floating-point libraries on-chip.

Flexible IO, including; 26 multi-function GPIO pins, 2 × SPI, 2 × I2C, 2 × UART, 3 × 12-bit ADC, 16 × controllable PWM channels.

8 × Programmable I/O (PIO) state machines for custom peripheral support.

Code it with C/C++ SDK or with MicroPython.

The Pico W is supplied with pre-soldered header pins that are compatible with breadboards and standard jumper wires.

Note:A USB cable is NOT supplied. One is available separately here

The Monk Makes solderless breadboard labelled for the Raspberry Pi Pico is the perfect prototyping solution for the Pico. Each of the Picos pins is labelled on the breadboard. When used in conjunction with a Pico with pin headers already attached, finding the right hole for your jumper lead couldn't be more simple.

The board has 400 tie points, 2 power buses and features an adhesive backing for securing your projects/prototypes. The board accepts wires, legs and male jumper connectors and allows you to build complex solderless circuits easily. The point spacing is a standard 2.54mm, making it compatible with any components/devices with a pin pitch of 2.54mm.

This RoHS compliant breadboard is rated for low voltage, low current only. Maximum for the Breadboard being 50V at 2A.

Features:

A solderless breadboard labelled for the Raspberry Pi Pico.

Each of pins on the Pico is labelled on the breadboard.

When used in conjunction with a Pico with pin headers already attached, finding the right hole for your jumper lead couldn't be more simple.

The board has 400 tie points, 2 power buses and features an adhesive backing for securing your projects/prototypes.

Standard 2.54mm point spacing.

RoHS compliant.

Compatible with:

Raspberry Pi Pico
