Raspberry Pi Camera Module 3

With the Kitronik Compact Robotics Board, the BBC micro:bit can be used to drive 4 motors (or 2 stepper motors) and 8 servos. Coupled with 17 other I/O expansion points, this means the BBC micro:bit can very easily become the core of a whole variety of robotics projects. The board is small on footprint but big on features and connectivity. Please note, when used with a stepper motor, half-stepping is supported - but not micro-stepping.

The Robotics Board features 2 Dual H Bridge Motor Driver ICs (capable of driving 2 standard motors or 1 stepper motor each) and 8 servo outputs (capable of driving standard and continuous rotation servos), all controlled from the BBC micro:bit using the I2C protocol via a 16 channel driver IC. Kitronik's custom MakeCode blocks make using I2C easy, even for novice users.

The Link header breaks out all the usable pins from the BBC micro:bit, and is designed to allow 2.54mm pitch pin header to be easily soldered into place. The 17 available I/O pins allow other input devices, for example, sensors, or output devices, such as ZIP LEDs, to be added to the board. The I2C communication lines are also broken out (Pins 19 & 20), which means other I2C compatible devices can also be added to the board and controlled by the BBC micro:bit.

Power is provided via either a terminal block or servo style connector. The supply is then controlled by an on/off power switch to the board. There is also a green LED to indicate when the board is turned on. The board then produces a regulated 3.3V supply which is fed into the 3V and GND connections to power the connected BBC micro:bit. This removes the need to power the BBC micro:bit separately. The 3V and GND pins are also broken out on the Link header, which means external devices can also be powered.

To use the compact robotics board, the BBC micro:bit should be inserted firmly into the edge connector, with the LEDs and buttons visible from the front.

Kitronik has produced a set of custom blocks for the MakeCode editor to simplify using the Compact Robotics Board for BBC micro:bit. To add them to the editor, select the cog icon in the top right of the editor. Then, select Extensions from the drop-down menu and in the search bar type and enter Kitronik. Pick the Kitronik robotics Board from the list and the new blocks will be added to the menu in the editor.

Features:

A compact yet feature-packed board designed to sit at the heart of your robotics project.

It can drive 4 motors (or 2 stepper motors) and 8 servos.

The board also has 17 other I/O expansion points.

The link header is designed to allow 2.54mm pitch pin header to be used.

The I2C communication lines are also broken out allowing other I2C compatible devices to be controlled.

This board also features an on/off switch and power status LED.

Power the board via either a terminal block or servo style connector.

The 3V and GND pins are also broken out on the Link header, allowing external devices to be powered.

Code with the Microsoft MakeCode editor with custom blocks by Kitronik or with Python.

When used with a stepper motor, half-stepping is supported - but not micro-stepping.

Contents:

1 x Compact Robotics Board for BBC micro:bit.

Dimensions:

Length: 68mm.

Width: 46.5mm.

Height: 10.6mm.

PCB Thickness: 1.6mm

The Raspberry Pi 5 includes two MIPI connectors designed for camera modules or displays. These connectors are more compact than those on previous Raspberry Pi models, so an adapter cable is required to connect your camera module.

Cable length: 200mm

These adapter cables feature a 22-pin, 0.5mm-pitch connector on one side for the Raspberry Pi 5, and a 15-pin, 1mm-pitch connector on the opposite side.

These camera cables DO NOT work with DSI displays.

These are 20cm long jumpers with male connectors on one end and female on the other. Use these to jumper from any male or female header on any board. Multiple jumpers can be installed next to one another on a 0.1" header.

Male to Female connectors

Pack of 40 x M/F Jumpers (four of each colour)

Length: 20cm (approx)

The Raspberry Pi Active Cooler provides an alternative cooling solution for users who wish to use their Raspberry Pi 5 under sustained heavy load without a case.

The Active Cooler combines a large metal heatsink with a high-quality variable-speed blower fan, powered and controlled via the fan connector on the Raspberry Pi 5, attached to the board via sprung pins into the dedicated pair of mounting holes.

As the heat from the Pi 5 CPU spreads across the heatsink body and fins, the blower fan pushes cool air over them to keep your Raspberry Pi 5 running at optimal thermal levels. The cooler uses thermal pads to create a solid thermal connection with the Raspberry Pi 5.

The fan is software-controlled, allowing it to remain off (and therefore silent) until temperatures reach the specified threshold.

Features

Compatible with Raspberry Pi 5

Large metal 'finned' heatsink combined with a high-quality blower fan

Fan fitting compatible with the Raspberry Pi 5 fan connector

Variable speed fan (software/temperature controlled)

Uses the Raspberry Pi 5 heatsink mount holes

Thermal pads included (pre-fitted)

Raspberry Pi not included

Compatible with:

Raspberry Pi 5
