60cm Male to Female Servo Extension Cable

This 30cm servo extension cable has three 22-AWG wires joining a male Futaba J connector and a female JR connector. Since a female JR connector can be plugged into a male Futaba J connector, each end of the cable is compatible with both Futaba and JR-style connections; this cable will work as an extension cable in either system or as an adapter between systems, and it is compatible with almost all of the servos in the Kitronik range

The connectors have contacts on a 0.1" spacing, and each wire is comprised of 60 strands, making this cable more flexible than standard servo cables.

Features:

Compatible with all standard servo types including a Mini 180 degree servo.

Also compatible with a Mini 360 degree continous rotation servo.

Servo cable colour convention:

Brown or black = ground (GND, battery negative terminal).

Red = servo power (Vservo, battery positive terminal).

Orange, yellow, white, or blue = servo control signal line

These are 20cm long jumpers with male connectors on both ends. Use these to jumper from any female header on any board, to any other female header. Multiple jumpers can be installed next to one another on a 0.1" header.

Male to Male connectors

40 x M/M Jumpers (four of each colour)

Length: 20cm (approx)

This FS90R Mini 360 Servo by Feetech is a great value multi-purpose micro size servo and it's ideal for use with micro-controller systems like the BBC microbit, Arduino, Raspberry Pi and PICAXE. It's miniature size also makes it great for use in radio controlled models and small robot projects.

This is a 360 degree continuous rotation servo. Its operation is very different to that of a standard servo. Instead of going to a specified angle, this servo will be static at a 1.5ms pulse (a trimmer is included to tweak this), a longer pulse gives forward rotation and a shorter pulse give backwards rotation.

The FS90R continuous rotation servo converts standard RC servo position pulses into continuous rotation speed. The default rest point is 1.5 ms, but this can be adjusted by using a small screwdriver to turn the middle-point adjustment potentiometer. Pulse widths above the rest point result in counterclockwise rotation, with speed increasing as the pulse width increases; pulse widths below the rest point result in clockwise rotation, with speed increasing as the pulse width decreases.

It comes with mounting screws and a range of horns to suit most applications. You can use any servo code, hardware or library to control these servos, so it's great for beginners who want to make things move without the need for a motor driver board. These servos are fully compatible with our Servo:Lite board which is also included in the :MOVE mini buggy kit for the BBC microbit.

Features:

Great value miniature servo.

360 Degree Operation.

Control horns included.

Contents:

1 x Mini 360 Degree Servo and accessories.

Dimensions:

Length:23.2mm.

Width: 12.5mm.

Height: 22mm.

Compatible with:

Raspberry Pi Pico

Micro:Bit

These are 20cm long jumpers with male connectors on one end and female on the other. Use these to jumper from any male or female header on any board. Multiple jumpers can be installed next to one another on a 0.1" header.

Male to Female connectors

Pack of 40 x M/F Jumpers (four of each colour)

Length: 20cm (approx)
