Plastic Motor Mounting Clips Pack of 10

Mount your In-Line Geared TT Hobby Motors firmly to your project with our plastic motor mounts. Made from yellow plastic, they are similar in colour to the motors they have been designed for.

The Geared hobby motors have a small protrusion on one side that fits neatly into the slots of the motor mount. This ensures that the motors don't slide about once they have been fitted. The mounts themselves are extremely snug and the motors will be held firmly in place.

The plastic motor mounts attach to your project/chassis via the 4 x M2 (2mm) mounting holes, 2 on each side. The mounts are very durable and will last the lifespan of your project and beyond.

The mounts are suitable for use with the In-Line Geared TT Hobby Motor.

Features:

Durable yellow plastic mounts for In-Line Geared TT Hobby Motors.

Once fitted they will clamp the motors firmly in place.

They feature 4 x M2 (2mm) mounting holes, 2 on each side.

Dimensions: For a complete set of dimensions, please see the product images.

Length: 29mm.

Width: 26mm.

Height: 15mm.

A combined motor and gearbox unit,especially designed for educational use. The motor operates between 1.5 and 6V DC, and the unit includes interchangeable gears, giving a range of speeds and motor torques.

The clear polycarbonate housing provides mounting for both the motor and gears, and full instructions for calculating gear ratios etc. are included.

Shaft 4mm dia. x 24mm long (front).

54mm long (rear).

Motor:bit is a motor driving board based on micro:bit. It has integrated a motor driving chip, which is used to drive two motors with maximun 1.2A DC single channel current. It has also integrated 12 GVS ports (for connecting OCTOPUS series of electric bricks) and 1 IIC communication port. These ports allow you to extend with various sensors and electric modules.

On the board, P3-P7, P9-P10 are IO ports for directly driving 3.3V devices; P13-P16, P19-P20(IIC port) support 3.3V/5V voltage switch. Sliding the voltage switch onboard, it is available to drive 3.3V or 5V devices. Besides, you can play music with the buzzer on motor:bit. Motor:bit is totally designed for DIYers. You can use it to create your own smart car or any funny projects.

FEATURES

Support 2 DC motors.

Max driving current of single channel is 1.2A.

Extend 14-channel IO ports and lead out it by GVS pins. Among it, 6 ports support 3V/5V voltage switch.

With 1 passive buzzer on board.

High torque 5 pole DC motor with wide operating range 12-24V. Suitable for water pumps, robotics etc. Rotation is counter-clockwise as viewed from shaft end.

Dimensions: L: 32.5 (exc. shaft) x 27.5mm dia.

Shaft: 12.8mm long x 2.3 dia.

Weight 52g approx.

Mounting holes 2 x M2.6 x 0.45 tapped.

RoHS compliant

Operating range: 12-24V (nominal 18V)

No load speed: 18000 RPM ±10%

No load current: 0.32A

Load speed: 14350 RPM ±8%

Current at max. efficiency: 1.3A

Rated load (with fan) 65g-cm

Output: 0.42W

Torque: 11.6g-cm

Stall torque: 55g-cm min.

Stall current: 1.4A max.

Add motor driving capability to the microbit with the Kitronik compact motor driver board for the BBC micro:bit. This motor driver board allows two motors to be driven simultaneously with forward, reverse & stop control, making it ideal for designs such as buggies. The board has a built-in short circuit, over current and thermal protection. Please note, when used with a stepper motor, half-stepping is supported - but not micro-stepping.

The board includes an integrated Edge Connector for your BBC micro:bit to slot into easily. It also features external connections to the button A and button B inputs. This allows additional switches/inputs to be connected to the motor driver board and the state of these can then be read by the BBC micro:bit.

There are 2 additional inputs/outputs. These can be used for connecting a range of parts and can be used in either digital or analogue modes.

Power is provided via either a terminal block or servo style connector, the supply is then controlled by an on/off power switch to the board. There is a green LED to indicate when the board is turned on. The board also produces a regulated 3V supply that is fed into the 40 way connector to power the inserted BBC micro:bit, removing the need to power the BBC micro:bit directly.

Kitronik has produced a set of custom blocks for the MakeCode editor to simplify using the Compact motor driver board. To add them to the editor, select the cog icon in the top right of the editor. Then, select Extensions from the drop-down menu and in the search bar type and enter Kitronik. Pick the Kitronik motor driver tile from the list and the new blocks will be added to the menu in the editor.

Features:

Ideal for designs such as buggies and other robotics projects.

Drive 2 motors with full forward, reverse and stop control.

Terminal blocks for easy connection of motors and inputs.

The 2 additional inputs/outputs can be used in either digital or analogue modes.

This board also features an on/off switch and power status LED.

Includes Edge Connector for the BBC micro:bit to slot into.

Provides regulated power to the BBC micro:bit.

Access the other BBC micro:bit pins easily and conveniently.

Program with the MakeCode editor or with python.

When used with a stepper motor, half-stepping is supported - but not micro-stepping.

Contents:

1 x Compact Motor Driver Board for the BBC micro:bit.

Dimensions:

Length: 68mm.

Width: 46.5mm.

Height: 10.6mm.

PCB Thickness: 1.6mm.
